DC 12V 24V Stepper Motor Pulse Signal Generator Module For Stepper Motor Driver Controller Speed Regulator 8~24V
Features:
1.this module is a pulse generation module, supply the control signal to stepper driver.
To control the stepper motor, it must be equipped with a drive.
2.this simple controller + stepper motor + stepper motor + DC power supply can be composed of a simple set of control platform.
3.the controller has high 5.4k-160khz, middle 540-16.6khz, low 80-2.4khz total of 3 kinds of low frequency signal can be used to select the jumper.
4.can produce pulse signal, can also produce PWM signal, can choose the jumper.
5.the frequency of measurement: PUL and common cathode end.
Different stepper driver may mark different name
EN=ENA=FREE Enable
PUL=PULS=CLK Pulse
DIR=CW=CWW Direction
Common anode Connection method (B)
EN+ PUL+ DIR+ connect together to com+.
EN- connect EN
PUL- connect CLK
DIR- connect DIR
Package Included:
1pcs * Pulse Signal Generator to Stepper Motor Driver Module
