1pcs Infrared LED Light 3W 850 Raspberry Pi Camera Board Module Night Vision Infrared IR

Instructions for Raspberry Pi Camera Infrared Night Vision Module

I. Usage Instructions

Connection and Adjustment:

Connect the LED light board to the camera PCB base plate with screws.

Adjust the adjustable resistor on the light board to enable the infrared lights to automatically turn on in dim light conditions and turn off in bright light conditions.

Compatibility Requirements:

This module must be used with the Raspberry Pi Camera (E) or (F) to achieve infrared night vision functionality.

Precautions:

Due to the limited power supply capacity of the Raspberry Pi, the externally connected 1W high - power light sensor will generate heat during operation (a heat sink can be externally attached).

Optimal shooting results are achieved for objects within 1 - 2 meters; distant objects may appear less clear.

II. Product Features

On - board 1W high - power 850nm infrared light.

On - board photoresistor for ambient light intensity detection.

On - board adjustable resistor for setting the ambient light intensity threshold at which the infrared lights automatically activate.

III. Product Images

(Note: This section should be supplemented with actual product photos; the above is a structural outline.)
