Monster Moto Shield

      Description: This is essentialy a ramped up version of our Ardumoto motor driver shield.   For this monster shield we've replaced the L298 H-bridgewith a pair of VNH2SP30 fullbridge motor drivers, we've also beefed up the support circuitry so this board is capable of driving a pair of high-current motors!   The VIN and motor out are pitched for our 5mm screw terminals (not induded), making it easy to connect larger gauge wires.

     Note: When using this board in extreme high-demand applications it may be necessary to improve thermal performance with a heat-sink or fan andto solder the wires directly to the board instead of using a screw terminal (in addition to the myriad other complications present in a hich-curentsystem) However, when using the board at currents up to 6A the chips will barely become noticeably warm.cimcu

Features:

● Voltage max: 16V

● Maximum current rating: 30 A

● Practical Continuous Current: 14 A

● Current sensing available to Arduino analog pin

● MOSFET on-resistance: 19 m (per leg)

● Maximum PwM frequengy: 20 kHz

Thermal Shutdown

Undervoltage and Overvoltage shutdown
