DC 12V Lift 800L/H Brushless Motor Submersible Water Pump Tool Ultra Quiet

Product Details of Stainless Steel Shaft Core DC Brushless Motor Submersible Pump (12V Small Water Pump)

1. Basic Parameters

- Voltage: DC12V (suitable for 7 - 14V), DC24V (suitable for 5 - 28V)

- Styles: Bare wire type; DC female head type (5.5×2.5mm)

- Power: 12V 19W; 24V 22W

- Flow Rate: 13L/min

- Head: 5.5M

2. Packaging Specifications

- Plastic Bag Packaging: Single pump weighs 220g,

- Size:8×7×5cm;

3. Product Features

- Low - Maintenance and Efficient: No maintenance required, small size, high efficiency, low power consumption, strong anti - interference, stable operation

- Long - Life and Clean: No carbon brushes, no pollution, electronic commutation, long service life

- Noise Reduction and Easy Installation: The lower mounting base plate can be replaced with shock - absorbing silicone to absorb vibration, reduce noise, and the silicone position is adjustable

- Fully Waterproof Design: The stator and circuit board are potted with epoxy resin, isolated from the rotor, solving the water seepage problem, completely waterproof

- Scene Adaptation: Solves problems such as pump jamming and startup failures in complex environments

- Wear - Resistant Shaft Core: The pump shaft core uses high - performance ceramics (zirconia, stainless steel shaft optional for cost reduction), with high precision and wear resistance, and precise matching of high - precision shaft sleeves and ceramic shafts
