DC 24V Linear Actuator 140KG Max Lift Stroke Electric Motor for Medical Auto Car

Note:

After receiving the package, please check the package contents. If you have any questions, please feel free to leave us a message!

Features:

1. With reliable performance, sensitive action stable running.

2. Good environment adaptability.

3. High quality metal material, high performance motor, built-in stroke switch.

4. Maximum push/pull is up to 150kg/140kg, and 3 stroke length can be chosen.

5. Commonly used in automotive, medical devices and engineering industry, agricultural machinery, wedding system, industrial electric lifting system, medical electric bed, surgical bed, traction bed, electric sofa, electric lifting lever, electric booth, electric sunroof, electric wheelchair, etc.

Specifications:

● Material: Metal

● Voltage: DC 24V

● Maximum push/pull: Approx. 150kg/140kg

● No-load speed: 5mm/s

● Relationship of speed and pull: 5mm/s(kg)-/ 50s(50kg)

● Environment temperature: -26°C to +50°C

● Standard protection level: IP54

● Built-in stroke switch: Yes

● Color: Silver

● Quantity: 1pc

Package Included:

1 x Linear Actuator

Note:

Due to different producing batches, product details might be a little different. If you minding the difference, please buy it careful.

Please allow 1-3cm differs due to manual measurement.

Due to the different display and different light, the picture may not reflect the actual color of the item. Thanks for your understanding.
