DS1302 DIY Rotating Digital LED Display Module Alarm Electronic Digital Clock Kit 51 SCM Learning Board 5V

Product Parameters and Function Description

1. Product Parameters

PCB Size: 51mm (length) × 81mm (width) × 81mm (thickness) (Can be powered by mobile phone chargers, power banks, USB ports)

MCU Program: The program has been burned; the light strip can be used directly after installation

2. Kit Functions

60 kinds of LED bead running patterns: Compatible with various LED magic color patterns, supporting speed adjustment, light running, stroke change, alarm clock setting (camera can be connected), flash switch (button needs to be connected), local meteor shower (can turn on/off rain and snow), time switch (10 scenes can be set to cycle execution). Suitable for store and large holiday atmosphere decoration, can create special effects such as meteor showers and waterfall lights.

3. Product Features

Adopt nixie tube to display brightness design

All - through - hole component design, with a production success rate of up to 99.9%

Equipped with 6 buttons for convenient function setting

The alarm stops automatically after the time is up to avoid disturbing people

Equipped with four kinds of status screens, with excellent display effect

Time is displayed by brightness, no additional operation is needed to check the time in a dark environment

With one - key troubleshooting button, convenient for fault

With light control function, can automatically adjust brightness according to the environment (manual brightness setting is also possible)

4. Gameplay Instructions (Two modes optional, subject to actual situation)

Mode 1 (Simple Version): Follow the steps below to realize the function

Installation: For the components on the corresponding chip, install according to time and alarm clock (need to re - operate after failure or going far away, can add quantity and status at one time to simulate meteor shower status)

Simulation: For the space on the corresponding magnet, display the clock status, can simulate setting status
