This presents specifications for different types of electrical components related to AC3 motors.
● For the QCX2-09A (220V) type: With a rated power of 2.2Kw/3Hp for AC220V and 4Kw/5.5Hp for AC440V, the operational current is 9A, and the rated heating current is 25A.
● For the QCX2-12A (220V) type: The rated power is 3kW/4HP for AC220V and 5.5Kw/7.5Hp for AC440V, with an operational current of 12A and a rated heating current of 25A.
● For the QCX2-18A (220V) type: It has a rated power of 4kW/5HP for AC220V and 7.5Kw/10Hp for AC440V, an operational current of 18A, and a rated heating current of 32A.
● For the QCX2-25A (220V) type: The rated power is 5.5kW/7.5HP for AC220V and 11Kw/15Hp for AC440V, the operational current is 25A, and the rated heating current is 40A.
● For the QCX2-32A (220V) type: With a rated power of 7.5kW/10HP for AC220V and 15Kw/20Hp for AC440V, the operational current is 32A, and the rated heating current is 50A.
